90-Degree Vent Scoop
Created today
Description
A duct transition scoop designed to pull air horizontally from a rectangular wall vent and direct it straight up into a 6-inch inline duct fan.
Sizing and Interface
- Wall Vent Opening: Fits over a 360mm × 210mm exhaust.
- Flange Size: 430mm × 250mm, featuring recessed tracks for 12mm wide foam weatherstripping.
- Top Socket: 157mm ID female slip-fit, sized for standard 6-inch ducting hardware.
- Hardware: Counterbored for #6 wood screws to anchor securely.
Images
