95mm Topographic Map Coaster Set

Made by a Guest

Created 3 months ago

Kitchen & Bathroomtopographiccoaster-sethousewarming-giftcontour-linesspill-catchergrid-base
Remix this model →

Description

A four-piece set of 95mm square coasters that arrange into a single continuous topographic map. Intended as a functional housewarming gift, each piece features recessed grooves along the contour perimeters to capture condensation and prevent runoff.

  • Dimensions: 95mm × 95mm × 8mm per coaster (190mm × 190mm assembled footprint).
  • Contour Geometry: 2mm vertical steps with 1.5mm recessed drip-catch grooves.
  • Base Features: Underside grid pattern provides grip and prevents surface sliding.
  • Spill Containment: Raised perimeter rim captures pooled liquid.
