AeroFit — Micro Motor Mount
Created 1 months ago
Description
A lightweight, minimalist motor mount designed to attach micro brushless motors to a standard 3.0mm carbon fiber boom. It prints flat on the bed with no supports required, making it an extremely quick and clean print.
Features
- Carbon Boom Sleeve: Snug 3.0mm inner diameter with a flex slit, allowing it to clamp securely to standard RC plane tail booms.
- Motor Interface: 9x9mm hole pattern sized for M2 screws, standard for 11xx series micro motors.
- Lightweight Build: Thin 1.2mm walls keep weight to an absolute minimum while the conical transition fillet maintains structural rigidity.
Print Notes
- Print upright (motor plate flat on the bed).
- No supports needed.
- PLA or PETG recommended for stiffness.
