GlideTrak — Under-Shelf Stemware Rack
Created today
Description
GlideTrak is an under-shelf stemware storage block designed to securely hold up to four standard wine glasses upside down by their stems. The dual-channel architecture features a continuous track that flares wide at the opening, allowing smooth, one-handed retrieval and stowing of glasses without requiring precise visual alignment. Engineered as a robust mounting block, it secures flush against the underside of a cabinet while maintaining a clean profile.
Features
- Flared Entry: The stem slot narrows from a 14 mm flared opening down to a 9 mm continuous track, guiding standard stems seamlessly into place.
- Concealed Mounting: Six countersunk holes with screwdriver access tunnels provide secure upward mounting, hiding the screw heads deep within the block.
- Support-Free Printing: Engineered to be printed standing vertically on its flat back wall, allowing the internal cavities to form cleanly without the need for support material.
Dimensions
- Overall Footprint: 212 mm wide × 170 mm deep × 22 mm thick.
- Base Clearance: 82 mm wide internal cavity per channel to accommodate standard glass bases.
- Stem Track: 9 mm track width, expanding to a 14 mm flare at the front entry.
Photos
Technical views
More like this
Explore more in Kitchen & Bathroom →
Staggered 6-Mug Wall Rack
