GripWedge — Hookable Doorstop

Made by a Guest

Created 3 months ago

Home & Fixturesdoorstopwedgecross-hatchedfinger-loopno-slipfunctional
Remix this model →

Description

GripWedge is an 8-degree angled doorstop designed to slip smoothly under low clearances while providing maximum hold against heavy doors. Featuring a cross-hatched upper grip texture, it resists slipping or sliding once engaged. A tall rear finger loop extends at the back of the wedge, allowing it to be easily yanked out without needing to bend down.

Features

  • Shallow Angle: Rises at a gentle 8 degrees, sliding cleanly under low 5mm threshold gaps.
  • Smooth Entry: The front 25mm of the wedge is left smooth for a snag-free initial slide.
  • Cross-Hatched Grip: Aggressive surface ridges grab the bottom of the door to prevent shifting under weight.
  • Quick Release Loop: The integrated rear hoop can be grabbed by hand or hooked with a toe for easy removal.

Dimensions

  • Length: 100mm
  • Width: 35mm
