Inline Fan Duct Adapter

Made by WittyManta

Created 3 months ago

Home & Fixtureshvacduct-adapterinline-fanwall-ventairflow-redirectventilation
Remix this model →

Description

A large, wedge-shaped adapter designed to redirect airflow from a standard rectangular wall vent up into a wall-mounted inline duct fan.

  • Wall Interface: Features a 400x230mm mounting flange that sits flat against the wall, dropping flush onto a concrete footing at the base for structural support.
  • Airflow Path: Converges a 360x210mm rectangular intake into a 6-inch (157mm ID) straight-sided vertical socket. All internal corners are filleted to prevent sharp airflow turns, minimizing stall and turbulence noise.
  • Sealing: Includes an 8mm foam tape channel around the back of the flange and a 12mm channel under the bottom foot to ensure a tight seal against both drywall and concrete.
  • Mounting: Six countersunk holes for #6 wood screws keep the fastener heads flush with the internal flow path.
