Description
A streamlined, one-piece 50 mm watch case with a 22 mm lug width. The edges have been significantly rounded for a softer, more refined profile on the wrist. Features a classic coin-edge bezel aesthetic with engraved minute markers and an inverted triangle at 12 o'clock.
Standard 22 mm spring bars will fit the 1.3 mm lug holes. The central cavity is a straight cylindrical fit, ready for a 36 mm movement or a custom dial insert.
Images
What it's for A two-piece case that turns a 44mm Apple Watch SE (1st gen) into a keychain fob, with no wrist strap. A back shell cradles the watch and carries the key-ring lug. A front bezel fits over it and holds the watch in, leaving the screen open. Dimensions Cavity: 38.6 x 44.6 mm, sized for a 44mm watch body with about 0.3 mm of clearance Outer size: about 44.6 x 50.6 mm, plus the lug Wall thickness: 3 mm Key-ring hole: 5.5 mm Side window on the crown/button edge: 27 mm long, so the Digital Crown and side button stay usable Screen opening: about 1.75 mm of lip around the display Print notes Both parts are laid out separately on the plate. The bezel is flipped so its lip prints flat. Print in PETG or PLA. Check the fit on the stepped joint and sand it if it is tight. The halves are a press fit, and a drop of glue will make the joint permanent. Remix ideas Add a lanyard slot or a carabiner notch. Emboss initials on the back. Make a version for 40mm watches by shrinking the cavity.
Cinque portachiavi con una raganella in rilievo e la scritta FAMIGLIA RAGANELLA, per distinguere le chiavi di casa senza provare tutte le copie. Misure e stampa Piastra: 34 × 44 mm, spessore 3 mm Foro per l'anello: 5 mm Rana e scritta in rilievo, circa 1 mm sopra la piastra Stampa piatta, senza supporti, anche con PLA
Round screw-top keychain container: a deep base with a 35 mm bore and a thin matching lid with an ornamental rim and a twelve-petal rosette centre. Fit Bore: 35 mm diameter, 10 mm deep. Thread: 42 mm major diameter, 2.5 mm pitch, lid cut 0.7 mm oversize. Outer diameter: 48 mm on both pieces. Keyring tab: 4.8 mm hole, on the outside of the base. Check before printing Measure how your printer holds the 35 mm bore. Print the lid first to test the thread fit. Not included No Arabic calligraphy. The lid uses a geometric rosette and scalloped border.
Pin con forma de mano esquelética cerrando el puño y con el dedo medio levantado. El dedo medio sube recto con sus tres falanges; el índice, el anular y el meñique quedan plegados hacia la palma. El pulgar va por detrás de los dedos plegados, así que solo asoma por el lado izquierdo y entre los huesos. Los huesos son blancos y de estilo realista: cada uno tiene una diáfisis fina y dos cóndilos redondeados en cada extremo, con una muesca central, y el extremo superior algo más pequeño. Las divisiones negras entre huesos marcan las articulaciones. En la palma hay cuatro metacarpianos y en la muñeca un grupo de huesos del carpo pequeños. La placa negra de 2 mm sigue la silueta de la mano y sobresale como borde. Los huesos van elevados 0,9 mm sobre ella, con la parte trasera completamente plana. La pieza mide unos 23 × 36 mm, así que queda 1 mm por encima de los 35 mm; el grosor total es de unos 2,9 mm. Para ajustarla al límite de 35 mm, reduce el borde de la placa. Placa negra plana de 2 mm; huesos blancos elevados 0,9 mm Huesos segmentados y separados por huecos negros de articulación, todos apoyados en la placa Sin piezas flotantes; se imprime como una sola pieza Sin soportes: la parte trasera es plana y los detalles se elevan desde la placa Huecos estrechos entre huesos; pensados para una boquilla de 0,4 mm
What it's for A round holder for a 21 mm by 2.5 mm disk, with an eyelet on each side for a strap, cord or ring. A 0.5 mm lip around the top edge snaps over the disk to keep it in place. Dimensions Outer diameter: 27 mm, 4.7 mm tall Disk pocket: 21.4 mm diameter, 2.5 mm deep Retaining lip: 0.5 mm overhang with a tapered lead-in Rear window: 17 mm, for pushing the disk out Eyelets: 4 mm holes, 9 mm pads, on both sides Remix ideas Increase the lip overhang for a firmer grip Remove the rear window for a closed back Add text or a chamfer ring around the edge
Bharat Key is a miniature Indian-style number plate keychain made to carry the exact registration PB 65 BK 3388. The long, slim plate uses a light grey/white base, a thin raised black border, and bold black lettering raised on one horizontal line. The single keyring hole sits at the extreme left with a raised ring around it for strength, while the registration stays centred in the remaining space. No blue IND strip, flag, extra colour or decoration is present, so the tag keeps a clean plate look while staying sturdy enough for a keyring. Dimensions Plate: 75 × 20 × 2.5 mm Raised border and text: 0.6 mm above the base; border 1 mm wide Lettering block: about 57 × 11 mm, fitted to the space right of the hole Keyring hole: 4 mm diameter, cut fully through at the extreme left Hole ring: raised black ring around the hole for extra strength Features Exact registration text: PB 65 BK 3388 on one horizontal line Bold black lettering raised above a light grey/white base Thin raised black border around the whole plate One circular keyring hole at the extreme left, fully through the plate Raised black ring around the hole to reinforce the keyring area Flat rectangular body with slightly rounded corners and a smooth flat backside Light grey/white base and black details only — no blue, no flag, no logos or decorations Print notes Print flat on the back; no supports are needed. The raised border and lettering sit 0.6 mm above the base and read clearly at miniature scale. Keep the 4 mm hole clear so the plate hangs cleanly on a keyring.
