Panneau de Consignation Modulaire
Created today
Description
Un grand panneau de consignation mural conçu pour s'imprimer à plat. Les plots d'accroche compacts calent les anses des cadenas, et le pas est calculé pour laisser les corps en suspension libre sans qu'ils ne tapent.
- Entraxe vertical : 90 mm pour cadenas de 89 mm de haut.
- Bossages : Rainures en U sans perçage, bord avant de 2,5 mm.
- Assemblage : Joints à queues d'aronde intégrés sur les quadrants.
Images
More like this
Explore more in Workshop & Tools →
2 cadenas module
