Description
A two-part, refillable container sized specifically for bulk dental floss spools. The internal chamber measures 40mm in diameter and 12mm deep, accommodating standard high-capacity reels, while an 8mm central post keeps the spool stabilized during use.
The dispensing mechanism runs through the side wall and eliminates the need for metal hardware. A dedicated exit path feeds the line out sideways into an integrated V-notch. Pulling the floss downwards wedges it into the sharp interior angle to pinch and snap it cleanly.
Design features include:
