Tumbling Travel Soap Box
Created 1 months ago
Description
A heavy-duty soap container designed for gym bags and travel. The deep 8mm friction-fit lip prevents accidental opening when tumbling around, while integrated 5mm ribs on both the top and bottom interior surfaces keep the soap suspended out of any pooled water, no matter which way the case ends up facing.
- Integrated Ribs: 5mm tall standoffs in both halves ensure the soap dries evenly.
- Deep Closure: An extended interior lip locks the lid securely in place without extra latches.
- Two-Piece Design: Eliminates loose inserts that could rattle or fall out during use.
Images
