Description
A screw-mounted under-desk hook designed to hold over-ear headphones without damaging them. Features a wide, flat rest area shaped like a shallow U to prevent denting or creasing the headband pad during storage.
Keep the model oriented flat on its side on the build plate. This ensures the layer lines run continuously along the length of the hook, maximizing strength and preventing it from snapping under the weight of the headphones.
Images
A Flex Mini 2.5G that sits loose in an under-desk bracket slides out the open end the first time someone bumps a cable. This mount screws to the desk underside and closes that end with a slide-in cover. Pocket: 110 × 72 × 28.5 mm, 5 mm bottom lips, wide port window in the front wall, cable slot in the -X end. Cover: 2.8 mm plate slides up into a 3.2 mm slot at the +X end. Four small bumps hold it by friction. Mounting: two countersunk screw ears on the top plate. Print: mount with the top plate face down; cover flat as laid out. No supports needed for the cover. Check the pocket size against your unit before printing.
What it's for A minimalist desk organizer with four open-top compartments for pens, pencils, markers and small stationery. A stepped front lowers the front pair for easy reach to small items, and a small NEXUS logo is engraved on the front face. Dimensions Footprint: 120 × 80 mm Height: 95 mm rear, 60 mm front Wall thickness: about 2.4 mm Flat base, rounded vertical corners, chamfered base edge Remix ideas Change the logo text to a name or initials. Make the front compartments deeper for scissors or rulers. Add a non-slip pad under the base.
A phone stand for a phone that keeps sliding flat or tipping over: a 60° backrest holds it upright, and a front lip stops it sliding out. Key numbers Base: 100 × 60 mm, 2.2 mm thick Backrest tilt: 60° from the table Slot: 12 mm wide, measured between backrest and front lip Walls: 2.2 mm throughout Corners: rounded in plan and along the profile edges Printing Print with the base flat on the bed. No supports needed: the backrest leans back at 60°, which stays within a typical overhang limit. Phones with thick cases may need a wider slot.
Tromba Perch è una coppia di staffe laterali indipendenti per una tromba 220x160 mm con interasse fori di 240 mm. Senza traversa centrale, ogni staffa si avvita sul monitor con la propria base e regge un lato della tromba. Si risparmia materiale e ogni pezzo entra facilmente nel piatto di stampa. Features Interasse fori tromba invariato: 240 mm in orizzontale, 126 mm in verticale Pilastro allargato verso l'esterno fino a filo del triangolo Triangolo a telaio con montante di irrigidimento Base da 125 mm con fori di fissaggio anteriori (asole regolabili) e posteriori Fori tromba da 6,4 mm per perni M6, foro basso asolato per regolare l'inclinazione In the box Staffa sinistra Staffa destra 4 dadi M6 da 7 mm, stampati a parte Print notes Le due staffe sono pezzi separati, senza giunto Filettatura stampata in PLA fragile: per carichi veri meglio dadi metallici
A dual-joystick controller enclosure that can't be wired or soldered through the top, because the two 52 × 52 mm joystick openings are too small for the board. This version splits the floor off as a removable bottom cover, so the board and joysticks go in from below. Key numbers Outer size when assembled: 165 × 105 × 35 mm (shell 33 mm + cover 2 mm) Walls and top panel: 2 mm; corner radius R6 Joystick openings: two at 52 × 52 mm, R3 corners, 14 mm apart RJ45 window: 25 × 18 mm, centred on the rear wall, 6 mm up from the open edge (provisional) Cover lip: 0.3 mm clearance inside the walls, 3 mm tall Printing Shell: print top panel down, open side up, no supports. Cover: print flat with the lip pointing up. Check the 25 mm bridge over the RJ45 window in the slicer preview. The cover is held by friction or a dab of adhesive; there are no screws.
A compact stacked rack that holds four 2.5" SSDs, each sliding into its own open-front slot. Side windows and diamond-shaped rear vents keep air moving and leave room for cables. Remix hooks Slot height (sw, 10.5 mm): sized for 7 mm drives with margin; raise to ~12 for 9.5 mm drives. Bay count (n, 4): change it and the body height follows. Slot width (76 mm) and depth (100 mm): tuned for 69.85 x 100.5 mm drives; adjust for other trays. Vent shape: swap the diamond rear vents for round ones or a slot pattern. Feet: the two rails (3 mm tall) can be removed, widened, or swapped for screw tabs. Pairs with: a SATA hub, or a second rack stacked side by side.
