1/2-Inch PEX Drip Manifold
Created 1 months ago
Description
A 4-way water distribution block designed to feed 1/2" PEX lines from a central throttled bore.
The core housing features a squared-off body for easier clamping, with four radial M16-threaded barbs ready to grab PEX tubing. Unused lines can be sealed using the included dead-end caps. The central bore houses an adjustable M20 needle valve to throttle the overall flow rate, and the entire assembly can be anchored into the dirt via a removable M14 spiked stake.
Critical Fitment
- Barbs: Sized for standard 1/2" ID PEX (barb OD peaks at 12.5mm).
- Base socket: The M14x2 stake receiver is a blind hole; you can run the manifold loose on the ground without water bleeding out the bottom.
- Clearances: Ensure your slicer allows roughly 0.3mm to 0.4mm clearance for the internal threads on the valve and caps.
Photos
Technical views
More like this
Explore more in Home & Fixtures →
4-Way Barb Manifold
Hoses slipping off a plain tube is a guaranteed flood. This 4-way manifold uses aggressive, precisely sized barbs to bite into soft tubing, routing one 8mm inlet into four 5mm outlets. Critical Fit Inlet: 8.2mm main shaft, 10mm max OD on three barbs. Outlets: 5.2mm main shaft, 6.7mm max OD on two barbs each. Flow: Internal bores are necked down to 3mm on the branches to preserve wall strength, expanding to a 16mm central chamber. Print it base-down. The horizontal barbs are short enough to bridge without supports if your part cooling is dialled in.
Halo Drip Irrigation Ring
This is a low-profile, continuous-loop irrigation ring designed for automated watering systems. It distributes water evenly around the base of a plant without interfering with the stem. The structure is engineered specifically for FDM printing without supports. The internal hollow channel features a teardrop cross-section so the printer can bridge the ceiling cleanly, and the external hose barb includes a small, built-in support block connecting it to the build plate. Design Notes Dimensions: 197 mm outer diameter, 173 mm inner diameter, leaving a 12 mm wide profile. Inlet: Dual-barb fitting sized for 5 mm internal diameter tubing, pointing outward to keep the hose clear of the foliage. Distribution: 12 downward-facing 1 mm drip holes spaced every 30 degrees, beginning 15 degrees offset from the inlet to ensure the first drops don't pool at the connection. Mounting: Three low-profile tabs sit on the outer perimeter, drilled for standard wire pegs to anchor the ring into the soil.
4-Way Water Manifold
A compact, print-in-place water manifold built for automated plant irrigation systems. It splits a single main feed into four independent channels with smooth internal transitions to minimize flow restriction. Inlet: Single center-mounted fitting sized for 8mm ID hose. Outlets: Four equally-spaced fittings sized for 5mm ID hose. Barbs: Dual retaining ridges on all connections to prevent slip-offs under pressure. Internal Channels: Fully hollowed 7mm common chamber with spherical transitions to eliminate dead zones and sharp fluid corners.
Anti-Spill Armrest Caddy
Sofa arms are basically designed to launch drinks onto the rug the second you shift your weight. This drops a rigid U-channel over the armrest to bridge the gap, locking down a flat staging plate on one side and a deep cup holder into the other. Specifications Total Length: 200 mm Inner Channel Width: 185 mm (verify this clears your sofa arm) Cup Holder: 80 mm diameter, 32 mm depth Print Specs: Prints hollow to save time and material. No supports needed if your bridging is dialled in.
Pendant Canopy With 50mm Mount
