6-Camion

Made by RussetYak

Created 1 months ago

Decor & Displayarabic-textplaqueparade-truckunity-dayembossed-signno-supports
Remix this model →

Description

What it's for

A commemorative 3D-printable plaque featuring the Arabic phrase "عيد الوحدة" (Unity Day) in raised, bold typography. Designed to be mounted on a parade truck cargo box, the lettering is heavily embossed to ensure clear visibility from a distance.

Dimensions

  • Backing Plate: 300 mm x 90 mm x 4 mm thick
  • Raised Text: 4.5 mm relief height above the plate
  • Mounting Holes: 4x symmetrically placed holes, 3.5 mm diameter

Print notes

  • Material: White PLA or similar rigid filament is recommended for high contrast.
  • Orientation: Print flat on the text side up (Z=0).
  • Supports: None required. Ensure good bed adhesion to prevent warping on the 300 mm span.
