Cali-Burrito Chibi

Made by a Guest

Created 3 months ago

Decor & Displaycali-catcalibration-testlow-polydonkeychibino-supports
Remix this model →

Description

Un burro de calibración estilo low-poly. Ideal para comprobar tolerancias y voladizos en impresiones rápidas, con el innegable encanto geométrico de las clásicas piezas de calibración pero en forma de burrito.

Detalles de impresión

  • Ojos y nariz: Grabados a apenas tres capas de profundidad (0.6mm), lo justo para crear sombra.
  • Patas y orejas: Construcción recta biselada para evitar la necesidad de soportes.
  • Base: Completamente plana sobre el origen.
