Experimental Filter Housing V1
Created 1 months ago
Description
A multi-part FDM-optimized housing for testing granular and particulate filter media. Designed with discrete chambers, retaining grids, and standard O-ring sealing surfaces.
Disclaimer: This is a strictly non-certified prototype for experimental projects. Do not use for certified respiratory protection.
What it's for
Testing layered filtration concepts. The housing accommodates a 26mm deep granular adsorption bed and an 8–10mm particulate filter section, separated by an air-distribution spacer. Media is retained by drop-in mesh grids, allowing rapid replacement during testing.
Dimensions
- Overall Assembled Size: 80 mm diameter × 55 mm length
- Wall Thickness: 3 mm main shell
- Adsorption Chamber: 68 mm ID × 26 mm depth
- Connections: Rear standard 3-tab quarter-turn bayonet (35 mm OD tube)
Print notes
- Orientation: Parts are laid out flat on the bed. The front cap should be flipped 180° in your slicer so its top face rests on the build plate.
- Supports: None required. The bayonet tabs are modeled with a 45° chamfer profile to print cleanly without support material.
- Tolerances: Threaded interfaces are built with 0.5–1mm diametrical clearances to accommodate standard PETG shrinkage.
