Smart Goggles Frame with Hollow Arms
Created today
Description
Smart goggles frame with two temple arms that are hollow and open on the inside face, plus separate lens caps, an electronics box with cap, and hinge pins.
What it fits
- Frame hinge pockets take the 11 mm wide arm tabs on vertical 3.4 mm pin holes.
- Hinge pins are 3.0 mm, so they fit those holes with clearance.
Check before printing
- The arm cavity is open on the inside face and has no cover. Wall on the outer side is about 3 mm.
- Speaker slots and the right-arm USB-C and switch cutouts remain on the outer wall.
Does not include
- No cover plates for the arms.
- No hinge stop or spring.
