A classic Czech hedgehog tank trap, scaled for RC crawler courses, tabletop dioramas, or just sitting on a desk. Built from three intersecting L-beams around a solid center block, it’s oriented to stand securely on three legs with the bottom tips sliced flat for better plate adhesion and stability on hard surfaces.
Images
A half-relief take on a Victorian terraced house in OO gauge: brick front with quoins, mitred corners and a roof that pitches back at 45° from the eaves, like the shop-front buildings that sit flat against a layout backscene. The side walls rise in a 45° slope to meet the roof, and the two tiled roof panels are sized to overhang the front and both sides. Brick front with separate window and door inserts Two mirrored side walls, 15 mm deep, with sloped tops Floor piece spanning between the sides Two tile-pattern roof panels, 36 × 25 mm each 45° mitred corner joins
A semi-detached OO gauge house pair with stone walls, a one-piece roof, separate door and window inserts, and chimneys supplied as flat-pack panels. The two 72 mm frontages sit side by side (144 mm overall) with quoins only at the outer ends. Each chimney is four panels plus a capped top, printed flat and joined by a thin 0.4 mm web. A second web holds the windows and door together on the plate. Remix hooks Chimney slope: side panels run 9 to 18 mm high at 45°. Change the two heights to suit a different roof pitch. Panel thickness: 1.5 mm. Thicker panels give stronger glue joints. Web: 0.4 mm tall with 1.2 mm bars. Cut it away after printing, or thin it further. Pairs with: the L-shaped corner brackets (10 × 10 mm legs, 15 mm long) for gluing the walls square.
Gancho de garrafa de treino em J, 200 mm, com braçadeira bipartida na base: corpo fixo ligado à haste e tampa separada que fecha por encaixe de pressão ao redor da alça de 12 × 24 mm. Pontos de remix Snap-fit: ganchos flexíveis de 8 mm de comprimento, 1,8 mm de espessura e ressalto de 0,6 mm (armlen, armt, ridge). Entrada em rampa, retenção reta. Folga: 0,2 mm entre tampa e corpo (gap). Trava extra: furo M3 em gota atravessando tampa e corpo, com porca sextavada embutida no lado +X. Paredes: wallx (6,4 mm) e wallf (7,5 mm) definem o tamanho externo; reduza se o furo M3 for dispensado. Haste e gancho: inalterados, seção 10 × 14 mm, bojo de 40 mm, boca de 34 mm. Combina com: parafuso M3 e porca M3 (opcionais); imprima corpo e tampa separados em PETG ou PLA.
A single-arm servo horn for the SG90 micro servo, with a 3.2 mm linkage hole 12 mm from the output shaft centre. Fitment Fits: SG90 and compatible 9 g servos with the 21-tooth, ~4.8 mm output spline. Does not fit: MG90S metal-gear servos with a different spline count, or 25T servos such as MG995/MG996. Arm: 12 mm centre distance, 4 mm thick, rounded edges. Check before printing Test the spline bore on a scrap print. Bore size is ~4.9 mm with small tooth notches, and printer tolerance varies. Adjust it if the fit is loose or tight. The part prints flat with no supports, and PLA works.
Straight and curved RC track pieces sized to fit a 250 x 250 mm print bed, using the same 90 mm wide track and bulb-and-socket latch as the rest of the set. What it fits Built for printers with a 250 x 250 mm bed or larger. Mates with the existing 90 mm wide pieces (80 mm clear lane, 5 mm rails) through the same latch with 1 mm clearance. Pieces Straights: 50 mm and 150 mm (the 200 mm straight also fits). 180° hairpin at 70 mm centreline radius, about 230 mm wide. 30° at 250 mm radius, 45° at 200 mm, 60° at 150 mm, 90° at 120 mm. Check before printing The footprint of each piece is measured from the model, but measure your bed's usable area, since brims and clips reduce it. Does not fit The earlier 180° hairpin at 100 mm radius, the main junction (about 440 mm) and the multi-way junctions are larger than a 250 mm bed. The latches have not been test-fitted.
608 rulman yuvalı, M3 cıvata ve somunla kapanan iki yarım gövdeli, 2 vitesli kayar dişli şanzıman. Giriş milinde 12T ve 24T sabit dişliler, çıkışta 36T+24T kayar dişli kümesi bulunur; 1. vites 3:1, 2. vites 1:1 ve iki çiftte de eksenler arası mesafe 36 mm'dir. Altı parça ayrı basılır ve montaj ister: alt gövde, üst kapak, giriş mili, D profilli çıkış mili, kayar dişli kümesi ve vites kolu. Üst kapağın dış yüzeyinde, kapanmış halde kullanıcıya bakan tarafta 0,8 mm derinliğinde oyulmuş "benze" yazısı vardır. Kapak ters basıldığı için yazı tablaya oturmaz. Gövde iç duvarları hızlı baskı için 1,6 mm'ye inceltilmiştir; rulman yuvaları, cıvata kulakları ve mil uçlarının duvarları 2,4 mm'de kalır. Uyumluluk 608 rulman: 8 mm iç çap, dört adet. Rulman kullanılmazsa basılı kaymalı burç seçeneği vardır. M3 cıvata: yaklaşık 12–16 mm, altı adet; M3 somun altı adet. Mil uçları: giriş ve çıkışta 5 mm D profil veya 5 mm D delik. Dişli standardı: modül 1.5, 20° basınç açısı, düz dişli. Baskı öncesi kontrol Alt gövde ve üst kapak, baskı yerleşiminde yaklaşık 92 × 93 mm taban alanı kaplar; tabla en az bu ölçüyü almalıdır. 608 rulman yuvası 8 mm iç çapa göre çıkar. Rulman yerine basılı burç kullanılacaksa mil çapı aynı ölçüde tutulmalıdır. Gövde iç uzunluğu üç dişli konumu ve kayma payı nedeniyle yaklaşık 60 mm'dir; 36T dişli yüksekliği belirler. Uymadıkları 90 × 50 × 45 mm gövde ölçüsüne sığmaz. Gerçek dış ölçü yaklaşık 92 × 93 × 32 mm'dir. Tek kayar dişliyle 3:1 ve 1:1 aynı eksen mesafesinde elde edilemez; bu modelde kayar küme 24T+36T çift dişlidir. Hazır bir redüktörün yerine doğrudan geçmez; miller, dişliler ve gövde birlikte basılan bağımsız bir düzenektir. Destek malzemesi gerektirmeyecek şekilde düz yüzeyler tablaya gelecek biçimde yerleştirilmiştir. PLA veya PETG ile 0,2 mm katman yüksekliğinde basılabilir; dişliler ve miller için %40–60 dolgu, gövde için %20–30 dolgu yeterlidir.
