Hollow Sphere Keychain, 33 mm Screen Opening
Created today
Description
Two-piece hollow sphere keychain with a 33 mm round screen opening in the front and a 3.3 mm ring hole through the top wall. The halves snap together with small bead pegs and can be pulled apart by hand.
- Body: about 56 mm sphere with two ear bumps, 2 mm wall, flat front face
- Screen opening: 33 mm diameter, through the front wall into the hollow interior
- Ring hole: 3.3 mm, a plain hole through the top wall on each side, with no inner sleeve
- Joint: three bead pegs and undercut sockets, pull apart along the left-right axis
- Print: each half sits cut-face down, no supports needed for the outer curve
Images
More like this
Explore more in Keychains & EDC →
Star Apple Watch Keychain Enclosure
A rounded five-point star shell that holds an Apple Watch SE 44 mm (A2352) as a keychain, with the real display open at the front. Two printed parts: a front shell (print mating face down) and a rear cover (flat face down) joined by four M2 screws. Remix hooks Watch fit: case 44 x 38 mm, 0.4 mm clearance per side, cavity depth 11.2 mm, corner radius 8 mm. Change clr, D and cav_r to tune the fit. Display window: 38.4 x 32.8 mm. This is an estimate, so confirm it against the watch. Crown, button, mic and speaker cutouts: positions are placeholders on the right and left sides. Measure the watch and move them before printing. Star size: the star_pts radii (50 / 33 mm) set the roughly 80 mm span. Shrinking the valley radius thins the wall near the cavity corners. Keyring hole: 5 mm at the top point. Raise ringd or move ringpos for a bigger ring. Charging opening: 32 mm round hole in the rear cover (charge_d). Pairs with: M2 x 8 mm screws, a small split ring, or a TPU bumper variant. Still to verify Crown and button height and position Speaker and mic positions Exact display window size Rear sensor bulge depth Treat the first print as a fit prototype. It is not load-rated.
6 mm Ball-Joint Crystal Dragon, 42 Segments
