Made by LevelOrca
Created 1 months ago
Description
Three-piece parameterized camera bracket designed for modular assembly. The front plate features a 70x40mm diamond footprint with standard M3 mounting points. The center holder sleeves into the main bezel, capturing the camera body, while the rear plate locks the assembly and routes cabling.
Images
What it's for 30×40 mm 底板,前端带两片独立固定耳片,用于锁 SG90 舵机自带的安装耳。 Dimensions 底板 30×40×2 mm,圆角 R1,2 个 φ2 孔,孔距 22 mm 耳片各宽 4.2 mm、厚 2 mm、高 14.5 mm 耳孔 φ2,中心距 28 mm,孔内侧距耳片内边 0.2 mm Remix ideas 加宽耳片内侧以增加强度 恢复 U 型侧壁
A two-piece hinged clamp for a 38.5 mm motorcycle fork tube, with an L-shaped bracket that carries a 10 mm hole and a 4 mm wire slit for a turn signal post. The halves swing open on an M3 hinge pin and close with one M6 bolt and a hex nut pocket, so the fork stays on the bike. The hinge sits outside the ring on small webs, so the knuckles clear the opposite half when it swings. Bore: 38.0 mm Height: 24 mm, wall 3.5 mm Hinge pin: M3 × 30 bolt or 3 mm rod Clamp bolt: M6 with nut Print the front half with its L bracket, and the rear half separately
A semi-detached OO gauge house pair with stone walls, a one-piece roof, separate door and window inserts, and chimneys supplied as flat-pack panels. The two 72 mm frontages sit side by side (144 mm overall) with quoins only at the outer ends. Each chimney is four panels plus a capped top, printed flat and joined by a thin 0.4 mm web. A second web holds the windows and door together on the plate. Remix hooks Chimney slope: side panels run 9 to 18 mm high at 45°. Change the two heights to suit a different roof pitch. Panel thickness: 1.5 mm. Thicker panels give stronger glue joints. Web: 0.4 mm tall with 1.2 mm bars. Cut it away after printing, or thin it further. Pairs with: the L-shaped corner brackets (10 × 10 mm legs, 15 mm long) for gluing the walls square.
Gancho de garrafa de treino em J, 200 mm, com braçadeira bipartida na base: corpo fixo ligado à haste e tampa separada que fecha por encaixe de pressão ao redor da alça de 12 × 24 mm. Pontos de remix Snap-fit: ganchos flexíveis de 8 mm de comprimento, 1,8 mm de espessura e ressalto de 0,6 mm (armlen, armt, ridge). Entrada em rampa, retenção reta. Folga: 0,2 mm entre tampa e corpo (gap). Trava extra: furo M3 em gota atravessando tampa e corpo, com porca sextavada embutida no lado +X. Paredes: wallx (6,4 mm) e wallf (7,5 mm) definem o tamanho externo; reduza se o furo M3 for dispensado. Haste e gancho: inalterados, seção 10 × 14 mm, bojo de 40 mm, boca de 34 mm. Combina com: parafuso M3 e porca M3 (opcionais); imprima corpo e tampa separados em PETG ou PLA.
A single-arm servo horn for the SG90 micro servo, with a 3.2 mm linkage hole 12 mm from the output shaft centre. Fitment Fits: SG90 and compatible 9 g servos with the 21-tooth, ~4.8 mm output spline. Does not fit: MG90S metal-gear servos with a different spline count, or 25T servos such as MG995/MG996. Arm: 12 mm centre distance, 4 mm thick, rounded edges. Check before printing Test the spline bore on a scrap print. Bore size is ~4.9 mm with small tooth notches, and printer tolerance varies. Adjust it if the fit is loose or tight. The part prints flat with no supports, and PLA works.
Straight and curved RC track pieces sized to fit a 250 x 250 mm print bed, using the same 90 mm wide track and bulb-and-socket latch as the rest of the set. What it fits Built for printers with a 250 x 250 mm bed or larger. Mates with the existing 90 mm wide pieces (80 mm clear lane, 5 mm rails) through the same latch with 1 mm clearance. Pieces Straights: 50 mm and 150 mm (the 200 mm straight also fits). 180° hairpin at 70 mm centreline radius, about 230 mm wide. 30° at 250 mm radius, 45° at 200 mm, 60° at 150 mm, 90° at 120 mm. Check before printing The footprint of each piece is measured from the model, but measure your bed's usable area, since brims and clips reduce it. Does not fit The earlier 180° hairpin at 100 mm radius, the main junction (about 440 mm) and the multi-way junctions are larger than a 250 mm bed. The latches have not been test-fitted.
