5.9 mm Square Tow Hitch with Two Pin Holes
Created today
Description
Square-shank tow hitch for a 1/10 scale TRX-4 Bronco, with a small ball on the top face at the rear end and two vertical pin holes at the front end for R pin retention.
- Shank: 5.9 x 5.9 x 30 mm, 0.5 mm edge chamfer
- Ball: 3 mm diameter on a 2 mm neck, 26 mm from the front end
- Pin holes: one 2 mm and one 3 mm, vertical, centred at 4 mm and 9 mm from the front end
- Overall height: about 9.8 mm
- Suggested material: PETG or nylon, for strength at the small ball and neck
Images
More like this
Explore more in Automotive, RC & Hobby →
Dosenhalter mit Stangenklemme, Salud Amigo
