65° Kitchen Counter iPad Stand
Created today
Description
A wide, flat iPad stand for kitchen counters. The cradle sits at 65° from horizontal, a steep reading angle for recipes while standing. The underside of the base has a shallow recess that leaves a perimeter rim, so the edge seals against the counter and crumbs and flour are less likely to creep under.
What it's for
- Reading recipes on an iPad at standing height without bending over.
- Use on a kitchen counter, where the wide base resists tipping.
- The stopper at the bottom of the cradle holds the iPad's lower edge, and the two side tabs keep it from sliding sideways.
Dimensions
- Base: 240 × 170 × 5 mm, with 1.5 mm chamfered edges.
- Underside recess: 228 × 158 mm, 1.6 mm deep, leaving a rim around the perimeter.
- Cradle plate: 200 × 150 × 5 mm, tilted at 65° from horizontal.
- Bottom stopper: 8 mm deep and 11 mm tall, measured from the plate.
- Side tabs: 6 mm wide, 40 mm long and 16 mm tall, one on each side.
- Supports: five ribs, each 6 mm thick, spaced 45 mm apart under the cradle.
- Overall height: about 143 mm.
Print notes
- Print the base face-down on the bed. The underside recess then faces up and needs no supports.
- PETG or ASA suits a kitchen better than PLA, which softens in heat.
- The cradle prints as one piece with the base and ribs, so no assembly is needed.
Remix ideas
- Add a raised lip on top of the base to catch spills.
- Change the tilt angle for a lower or steeper view.
- Narrow the cradle and tabs for a smaller tablet.
- Add a cable slot in the stopper for charging while reading.
- Stick a thin rubber or silicone pad inside the rim for extra grip.
Images
More like this
Explore more in Kitchen & Bathroom →
Bag Holder Stand with Spring Clamp Ring
A freestanding stand that holds a freezer or piping bag open so both hands are free for filling. The bag mouth is pulled through a 120 mm inside-diameter ring, folded over the outside, and secured with a separate split clip that grips the folded rim all the way round. The base is a wide 270 × 250 mm plate with a rear post, so the stand resists tipping when a bag is loaded. The ring sits at the top of the post, 165 mm above the plate, with a flared lip to keep the fold from slipping off. Ring: 120 mm inside diameter, 40 mm tall, on a short arm off the post Base: 270 × 250 mm, 8 mm thick, chamfered edges, with a gusset on the post Clip: split spring ring, 24 mm tall, with finger tabs for opening Parts: base with post, ring, and clip are colour-labelled; the clip prints separately Material: PETG suggested for the clip so it keeps its spring To use, pull the bag mouth up through the ring, fold it down over the outside, then snap the clip over the fold. The ring height suits bags up to roughly 165 mm long; longer bags will rest on the base. The clip's grip has not been test-printed, so the gap may need adjusting for thicker or thinner bag film.
Three-Slot Curved Taco Stand
A taco stand that holds three shells upright and open-side up, so fillings stay in place while you load them. The base is a flat 180 × 120 mm block with rounded corners. Three curved slots are cut into it, each one cradling a single shell. Four round feet lift the base off the table. Each slot arcs along its length, which follows the curve of a folded shell. Three curved slots, each 90 mm long and 20 mm wide Slots spaced 55 mm apart across the 180 mm base Base 22 mm thick, with the slot floor 6 mm above the underside of the block Four round feet, 5 mm tall, with chamfered edges Rounded vertical corners on the base Prints flat on its feet, with no supports needed If your shells are wider than 20 mm, widen the slots before printing. Food-safe filament such as PETG is a sensible choice, and a wipe-down after use keeps it clean.
Obsidian — Ribbed Can Cooler with Handle
Obsidian is a matte-black-ready can cooler for standard 330 ml cans, with a reinforced side handle, diagonal grip ribs and a flat front panel reserved for names or logos. The handle opening has a peaked top so it prints upright without supports. Dimensions Inside diameter: 68 mm Inside height: 105 mm (above a 3 mm base) Wall: 2 mm, base: 3 mm Overall height: 108 mm; footprint about 115 × 74 mm including handle and panel Features Diagonal ribs outside, perfectly smooth bore inside Rounded top rim Broad, rounded handle, 24 mm wide Flat front panel, 40 × 66 mm Print notes Print upright, base on the plate, PETG, 0.4 mm nozzle, 0.2 mm layers No supports expected; fits a 180 mm build volume
Cucharilla de dos piezas con conector
What it's for Mango curvo tipo banana y conector independiente con dos pestañas flexibles. El conector encaja con un clic en el alojamiento del mango y se retira pellizcando las pestañas a través de las ventanas laterales, sin herramientas. Dimensions Mango: 120 mm de largo, 25 mm de ancho en la base y 20 mm en la punta, 16 mm de grosor. Alojamiento: 16 × 6 mm, 23 mm de profundidad. Conector: núcleo de 22 mm, 5,6 mm de grosor, brazos de 1,6 mm con resalte de clic. Ventanas laterales de 4 mm donde se aloja el resalte. Remix ideas Añadir una cabeza de cuchara en la pestaña tope del conector. Ajustar el grosor de los brazos (1,6 mm) para un clic más suave o más firme. Cambiar el radio de curvatura del mango.
Cutting Board Corner Grip Feet
