Lotus Flame LED Tealight Holder
Created today
Description
A Diwali LED tealight holder: a pointed, flame-shaped white frame stands on a round base, with a red lotus panel set inside it. The lotus is cut clean through the panel, so the LED glow shows through from the front cup. Five red petals wrap the cup, and two large white petals sweep out to the sides. Designed for battery LED tealights only, never real flames.
Remix hooks
- Cup size: 41.6 mm bore, 20 mm deep, 47.6 mm outside. Change the bore for a different tealight brand. Open top, so the LED lifts straight out.
- Flame silhouette: one width function sets the outline (about 40 mm half-width, 136 mm tall, standing on a 5 mm, 85 mm base). Change the exponents for a slimmer or fuller flame.
- Lotus pattern: the cutouts are a short list of ellipses (centre petal 11 x 44 mm). Add a ring or swap the shapes, and keep a 2 mm or wider web between openings.
- Colour split: red panel and front petals, white everything else. The panel sits in a 1 mm slot with 0.1 mm clearance on each face, so it prints flat and drops in. Swap in blue for an accent.
- Pairs with: a flat LED tealight, or a second panel with a different motif.
Starting dimensions
- Height about 140 mm
- Width about 120 mm across the outer petals
- Depth about 85 mm, set by the base
- Frame 8 mm thick, panel 3.5 mm thick
Images
More like this
Explore more in Decor & Display →
Christmas Tree Lantern with LED Holder
What it's for A Christmas tree lantern with perforated walls that hides a 38 mm battery LED light. A removable twist-lock tray inside the base holds the light, so it stays in the tree when the tree is carried or moved. Dimensions Base diameter: 90 mm, open underneath Total height: about 140 mm including the star Wall thickness: 1.6 mm Light ring: 39.4 mm inside diameter, 6 mm tall Tray: 66 mm disc with three locking lugs Assembly Line the tray lugs up with the gaps between the three tabs inside the wall. Push the tray up past the tabs, turn it about 60°, and lower it onto the tabs. Place the light in the ring. Remix ideas Make the ring taller for a deeper hold. Add a thumb notch to the tray for easier twisting. Change the hole pattern for different light dots.
Lotus Stem Diya Stand
