3D-printable storage & organizers
Boxes, wallets, dispensers, holders and carriers sized for real contents. Browse what makers built, or describe the exact organizer you need and Printy makes it.
Need one that fits your exact measurements? Start building →
Newest
TANKER 3 Water
A matched set of eight small label plates with bold raised white lettering, styled like the enamel signage screwed to a garage wall, a shelf edge or the front of a storage bin. Each plate carries a single word — the four blue plates read ROAD, CURB, REAR and REAR, and the four red plates read SCENE, DECK, TANK and TANK — so a wall of bins, hooks, shelves or parking spots can be told apart at a glance. Colour does the sorting: blue for one group, red for the other, both with the same white lettering, so the two families stay distinguishable from across the room while reading as one set. The letters are thickened rather than enlarged, so the strokes carry weight without changing the plate size. The plates are plain rectangles with rounded corners and no fixing hole, leaving the full face free for the text — stick them on with double-sided tape or adhesive, or drill and screw them wherever they are needed. Dimensions Each plate: 1.5 in wide × 1 in tall (38.1 × 25.4 mm), 2 mm thick Rounded corners, no hanging hole Raised lettering: 0.8 mm proud of the face, strokes thickened for a heavier face Lettering centred horizontally and vertically on every plate Plates laid out 32 mm apart in two columns, blue set on the left, red set on the right Set contents Blue: ROAD, CURB, REAR, REAR Red: SCENE, DECK, TANK, TANK Print notes All eight plates sit flat on the bed and print without supports A single filament swap at letter height produces the two-tone face; painting the raised text works just as well The whole set prints in one go and comes off as eight separate tags The same layout takes any short word you want to swap in, as long as the plate size and the two-tone face stay the same.
TANKER 3 Water
A matched set of eight small hanging plates with raised white lettering, styled like the enamel signage screwed to a garage wall, a shelf edge or the front of a storage bin. Each plate carries a single word — the four blue plates read ROAD, CURB, REAR and REAR, and the four red plates read SCENE, DECK, TANK and TANK — so a wall of bins, hooks, shelves or parking spots can be told apart at a glance. Colour does the sorting: blue for one group, red for the other, both with the same white lettering, so the two families stay distinguishable from across the room while reading as one set. Dimensions Each plate: 1.5 in wide × 1 in tall (38.1 × 25.4 mm), 2 mm thick Raised lettering: 0.8 mm proud of the face Hanging hole: 3 mm, at the left end of every plate Plates laid out 32 mm apart in two columns, blue set on the left, red set on the right Set contents Blue: ROAD, CURB, REAR, REAR Red: SCENE, DECK, TANK, TANK Print notes All eight plates sit flat on the bed and print without supports A single filament swap at letter height produces the two-tone face; painting the raised text works just as well Lettering is sized to keep ROAD and CURB clear of the hole with a small margin The whole set prints in one go and comes off as eight separate tags Mount them with a nail, a hook, a short loop of cord or a zip tie. The same layout takes any short word you want to swap in, as long as the size and the two-tone face stay the same.
TANKER 3 Water
Four small blue plates with raised white lettering, styled like the enamel signage you'd find screwed to a garage wall, a shelf edge or the front of a storage bin. Each one carries a single word — ROAD, CURB, and two marked REAR — so a set of bins, hooks or parking spots can be told apart at a glance. Every plate measures 1.5 in wide by 1 in tall (38.1 × 25.4 mm) and has a 3 mm hole at the left end for hanging on a nail, hook or short length of cord. The lettering stands 0.8 mm proud of the surface, which is what gives it that crisp two-tone look. The four plates are laid out 32 mm apart so the whole set goes on the plate in one go and comes off as four separate tags. Design notes Four plates per set: ROAD, CURB, REAR, REAR Raised white text on a blue face — a simple filament swap at letter height does it Hanging hole at one end; thread, wire or a nail head is enough to mount them Flat undersides, so they print cleanly with no supports Lettering sized to keep ROAD and CURB clear of the hole with a small margin Pair them with storage bins, a wall of hooks, or a shelf where the contents need naming rather than numbering. The same layout takes any short word or label you want to swap in — the plates read as a matched set as long as the size and the two-tone face stay the same.
Hinged Bass Tackle Box with Dividers
What it's for A hinged tackle box for bass fishing gear, with a locking front latch, removable thick dividers and a leaping bass on the lid with SMITH FISHING lettering. Dimensions Base: 240 × 160 × 50 mm, 4 mm walls, 3 mm floor Lid: 240 × 160 × 22 mm with raised artwork Dividers: 5 pieces, 2.6 mm thick, sliding in 3.2 mm grooves Hinge: 5 knuckles with a separate 4.2 mm pin Latches: 2 front latches with pivot pins Remix ideas Change the lettering to a different name Add more divider grooves for smaller compartments Swap the lid artwork for another species
Bass Tackle Box With Hinged Lid
Tackle boxes that pop open in the boat, rattle hooks into the soft plastics, or lose a lid hinge get replaced. This one is a hinged bass tackle box with a locking front latch, adjustable dividers and a leaping largemouth bass on the lid, with SMITH FISHING raised underneath. Load-bearing numbers Base: 240 × 160 × 50 mm, 4 mm walls, 3 mm floor, rounded vertical corners. Lid: 240 × 160 × 22 mm, with a raised bass, ripples, waves, hooks and a border on top. Dividers: 5 removable cross dividers, 1.8 mm thick, sliding in 2.4 mm grooves at 38.5 mm spacing. Hinge: 5 interleaved knuckles across the back, joined by a 4.2 mm pin (197 mm long, printed separately). Latches: 2 front latches with 4.2 mm pivot pins. Each hooks under a ledge on the base. Printing Print every piece in the layout shown: base, lid, dividers, latches and pins are all separate. Lid: print upright. The underside of the top plate bridges across the cavity, so use supports or good bridging settings. Layer height 0.2 mm, PETG or ASA, 3+ perimeters. Hinge and latch pins can be glued or capped at the ends to keep them in.
4x4 Gridfinity Baseplate with Bowtie Clips
What it's for A 4x4 Gridfinity baseplate that joins to neighbouring plates without interrupting the grid. Each outer edge carries four bowtie-shaped recesses on the underside, one centred on every cell edge. Butt two plates together and press a clip into the matching recesses from below; the clip sits flush so the top surface stays seamless and the 42 mm pitch carries across the join. The set prints as separate parts: the baseplate, the bowtie clips and a 1x1 bin. The bin has a foot profile that matches the baseplate pockets but no stacking lip. Dimensions Baseplate: 168 × 168 × 6.8 mm (4 × 4 cells on the 42 mm grid) 1x1 bin: 41.5 × 41.5 × 25.7 mm Bowtie clips: 16 × 79 × 1.2 mm, sitting in 1.4 mm deep recesses with 0.2 mm clearance Print notes Six clips are included, which is enough for one seam only — print four per cell edge you want to join. Print the clips flat in PETG or a tougher filament rather than PLA; at 1.2 mm thick they are the weak point of the set. Remix ideas Scale the plate to other grid sizes, or mix a 4x4 with smaller plates along the same seams. Add more 1x1 bins, or extend the bin family with deeper sizes. Add a stacking lip to the bin for stacked storage.
4-Hotend 8-Nozzle Holder for Elegoo Centauri 2
A storage holder for Elegoo Centauri 2 hotends and nozzles. The main block has four front-opening hotend pockets on a 32 mm pitch, each with snap-in retention ridges at the opening so a hotend snaps past and stays put. Four rounded-end magnet slots in the back face take press-fit magnets. Nozzles sit in two holders fused to the ends of the block, four 7.2 mm wells each in a 2 x 2 grid, labelled 0.2/0.4 on one side and 0.6/0.8 on the other. Each holder overlaps its block end by 3 mm, so the whole holder is one solid piece rather than separate clip-on parts, and the wells are shifted outward to sit clear of the block face. The front face is marked HOTEND above the pockets. Lightening slots through the dividers cut material use and print time. Specifications Overall footprint: approximately 170 x 22.8 x 90 mm including the fused side nozzle holders; the hotend block alone is 128 x 22.8 x 90 mm Hotends: 4 front-opening pockets, each 22 x 13 mm and 50 mm tall; check the pocket size against your actual hotend dimensions Retention: two rounded ridges at each pocket opening narrow it to roughly 18.6 mm, so a hotend around 20 mm wide snaps past and stays put Nozzles: 8 wells total, four per side holder in a 2 x 2 grid, 7.2 mm diameter x 14 mm deep Side nozzle holders: each about 24 x 22.8 x 30 mm, protruding roughly 21 mm past each end of the block with a 3 mm overlap; wells sit about 1.5 mm clear of the block face Labelling: 0.2 and 0.4 on one holder, 0.6 and 0.8 on the other, each label covering the two wells behind it; holder lettering is 3.5 mm tall Magnet slots: 4 stadium-shaped slots in the back face, 5.2 x 37 mm and 4 mm deep, for 5 x 37 x 4 mm rounded-end magnets, one centred in each column Text: HOTEND embossed 8 mm tall above the pockets, 0.8 mm proud; size numbers on the main block are 7 mm tall Lightening: 5 mm wide x 46 mm tall slots through the three dividers between columns, front to back Column pitch: 32 mm
Apothecary Grid Hinged Pill Box
A pharmacy-drawer grid in miniature: thirty round wells in a 6×5 layout, topped by a lid that swings open on a real pin hinge at the back edge. The lid prints flat beside the tray and clicks into the hinge ears once a short pin is slid through. 30 slots, 16 mm wide and 14 mm deep Hinge pin hole sized for a 1.75 mm filament offcut, about 56 mm long Front finger tab on the lid for easy opening Lid and tray print without supports in separate pieces
Rounded Rectangle Purse Base Left Half
The right half of this purse base keeps the quiet, rounded-rectangle silhouette of the full plate: a slim 4 mm slab with softly radiused corners that let fabric wrap without puckering. Two dovetail slots sit in its inner edge, cut clean through and sized with 0.3 mm clearance so the tabbed half slides in from above and sits flush. Alone, it is the slotted partner in a two-piece base; joined, the pair makes the full 14.5 × 4.5 in footprint for a bag bottom. This file is the right half only: about 184.1 × 114.3 mm, small enough to fit a 9 in (228.6 mm) bed. For a purse that will carry weight, glue the seam as well; under a lining it disappears. Design notes Footprint once joined: 14.5 × 4.5 in (368.3 × 114.3 mm) Thickness: 4 mm Corners: rounded, 15 mm radius This half: about 184.1 × 114.3 mm, with two dovetail slots Joint: slots cut through with 0.3 mm clearance; tabs on the opposite half slide in from above Print check: print flat on a 9 in (228.6 mm) bed; each half is its own file, so print them one at a time Use: a base layer for a purse or bag build — pair it with sides, lining or hardware as the pattern calls for
Hinged Latching Box With Front Divider
Small parts slide into one pile the moment the lid comes off; this hinged latching box splits the main space with a divider and adds a full-depth side bay so screws, clips and the like stop mixing. The main compartment clears 152 × 127 × 45 mm, with a 2.5 mm divider set 97 mm back from the front. A 2.5 mm wall separates a 28 mm wide, full-depth compartment on the right, and that bay has no cross divider. The walls stand 2 mm taller than the divider, and the divider top sits level with the underside of the lid lip, so the full 45 mm of height is usable. Fit and compartments Main compartment: 152 × 127 × 45 mm clear (width × depth × height). Right side compartment: 28 mm wide × 127 mm deep × 45 mm high, separated by a 2.5 mm wall and open for its full depth; overall inside width about 182.5 mm. Divider: 2.5 mm thick, 97 mm back from the front of the main compartment; front bay 97 mm deep, rear bay about 27.5 mm clear in the main area. The divider stops at the side-compartment wall so the right bay stays open. Walls and floor: 2.5 mm; the divider is 2 mm shorter than the walls so the lid lip clears it. Lid: 2 mm inner lip locates it on the base. Hinge clearance The lid's back edge has notches where the base's hinge knuckles pass through it. The base's back wall is cut away where the lid's knuckles swing down into it. Both cuts carry roughly 0.3 mm of play, so the lid closes without catching. Latch The hooked tab on the lid is set so the hook sits close over the catch bump without binding. Closed, the gap between the top of the hook and the underside of the catch bump is about 1.3 mm. If it prints too tight to snap over, lengthen the tab by a fraction of a millimetre at a time; if it is too loose, shorten it the same way. Printing and assembly Prints as three separate pieces: base, lid, and hinge pin. Base footprint is about 187.5 × 140.6 mm; the lid is about 187.5 × 142.3 mm; the pin is about 185.5 mm long and 3 mm in diameter. The pieces sit apart on the plate with gaps: the lid is flipped so its flat top face is on the bed, and the 3 mm pin lies flat in the gap. None of the three touch. If a slicer imports the file as one body, use Split to objects or Separate parts. Hinge: seven interleaved knuckles with a 3 mm pin. Use a 3 mm rod or filament, or print the pin. Slide the pin through the knuckles after printing; the lid hinges on it and the front latch holds it shut.
Pokémon Deck Box With Drawer2
A Pokémon-themed deck box with a lift-off Poké Ball lid, a card well and a separate pull-out drawer for dice and counters. Parts are laid out on two plates: the box body alone on plate 1, and the lid and drawer side by side on plate 2. Remix hooks Overall size: the body is 80 x 105 x 70 mm. Change W, D or H to fit larger sleeved decks. Card well: 68 x 93 mm. Widen it for double-sleeved cards. Drawer bays: one long bay for dice and two smaller ones, 32 mm wide. Re-split them for tokens or damage counters. Plate layout: the body is turned 90° so it sits along X on plate 1. Plate 2 is offset 160 mm along Y. Pairs with: a card divider set or a coin-flip token tray.
Pokémon Deck Box With Drawer2
A Pokémon-themed deck box with a lift-off Poké Ball lid, a card well and a separate pull-out drawer for dice and counters. Parts are laid out on two plates: the box body alone on plate 1, and the lid and drawer side by side on plate 2. Remix hooks Overall size: the body is 80 x 105 x 70 mm. Change W, D or H to fit larger sleeved decks. Card well: 68 x 93 mm. Widen it for double-sleeved cards. Drawer bays: one long bay for dice and two smaller ones, 32 mm wide. Re-split them for tokens or damage counters. Plate layout: the body is turned 90° so it sits along X on plate 1. Plate 2 is offset 160 mm along Y. Pairs with: a card divider set or a coin-flip token tray.
Drehverschluss-Deckel für Münzbehälter
Runder Deckel mit Drehverschluss (Bajonett, drei Nasen) für den zylindrischen Münzbehälter mit 40 mm Innendurchmesser. Der Deckel wird mit der Öffnung nach unten gedruckt, ohne Stützen. Außendurchmesser 52,4 mm, Höhe 12 mm Drei Verschlussnuten für das Bajonett 1 mm tiefe Vertiefung oben für die separat gedruckte Schrift Gedacht für weißes Filament Passt zum Behälter aus derselben Serie. Die Schrift wird als eigenes Teil gedruckt und eingeklebt.
Münzbehälter mit Drehverschluss, 26 mm
Zylindrischer Behälter für Kleingeld mit Bajonett-Drehverschluss. Der Innendurchmesser von 26 mm nimmt 10-, 20-, 50-Cent- und 1-Euro-Münzen auf, die Innenhöhe von ca. 45,5 mm reicht für rund 8 € in gemischten Münzen. Auf dem Deckel steht "knuppi" erhaben. Körper: Ø 31 mm, Höhe 48 mm, Wand 2,5 mm, drei Verriegelungsnasen Deckel: Ø 38 mm, Höhe 12,5 mm, drei L-förmige Nuten, Verschluss durch ca. 40° Drehung Schrift: 1,2 mm erhaben, Schriftart Bangers Farben: Körper schwarz, Deckel weiß, Schrift blau (Mehrfarbdruck oder Farbwechsel) Druck: Deckel mit der Öffnung nach unten, keine Stützen nötig
150×100mm U型三面围挡抽纸挡架
这是一个U型抽纸挡架，用于放入约150×100 mm的抽纸包。左、右、后三面围挡，前面完全敞开，便于抽取纸巾并减少纸巾滑落；底板、背板和侧板均为完整实心结构，无开孔、镂空或凹槽。整体为单件结构，无需组装。 规格 内部放纸区域：150 × 100 mm 外形尺寸：约154 × 102 × 52 mm 挡板高度：50 mm（底板以上） 总高：52 mm（含2 mm底板） 壁厚：2 mm 底板：整块2 mm实心平板，无孔洞 围挡方式：左、右、后三面围挡，前面敞开 背板与侧板：完整实心，无开孔 结构：一体打印，无需组装
150×100mm U型三面围挡抽纸挡架
这是一个U型抽纸挡架，用于放入约150×100 mm的抽纸包。左、右、后三面围挡，前面完全敞开，便于抽取纸巾并减少纸巾滑落；底板、背板和侧板均为完整实心结构，无开孔、镂空或凹槽。整体为单件结构，无需组装。 规格 内部放纸区域：150 × 100 mm 外形尺寸：约154 × 102 × 52 mm 挡板高度：50 mm（底板以上） 总高：52 mm（含2 mm底板） 壁厚：2 mm 底板：整块2 mm实心平板，无孔洞 围挡方式：左、右、后三面围挡，前面敞开 背板与侧板：完整实心，无开孔 结构：一体打印，无需组装
Two-Piece Rack for 14 Game Tiles
This stand holds fourteen game tiles upright and ready at the table. It is split into two halves that join at the middle with a dovetail, so it breaks down for storage. A low front lip runs along the front of the base, and the fixed back panel leans back 15° so tiles rest in a steady lean against it. The rack is sized for tiles about 17 mm wide, 7 mm deep and 24 mm high, and it has no dividers between tiles. To assemble, drop the tab on the left half down into the socket on the right half from above. The joint sits flush with the tray floor, so the tile slot stays clear. The tab is 3 mm tall, which keeps the halves aligned but is not a strong joint; a dab of glue makes it permanent. Both halves print flat on the plate and need no supports. The dovetail socket is cut to 0.04 mm clearance per side — about the limit for a typical printer, so the halves may not seat by hand. If they bind, sand the tab lightly. Holds 14 tiles sized for 17 × 7 × 24 mm Two halves, about 127 mm and 121 mm long as printed, joined by a drop-in dovetail with 0.04 mm clearance per side Overall length about 242 mm when assembled, leaving roughly 4 mm of slack across 14 tiles 8 mm deep tile slot in front of the back panel, giving about 1 mm of clearance over a 7 mm tile 2 mm front lip, 6 mm high, keeps tiles from sliding forward Fixed back panel about 23 mm tall, leaning back 15° No tile slots or dividers; tiles sit side by side in the tray Both halves print flat without supports
Drawer Organizer Grid for Mini Toolbox Top Drawer
Small screws, bits, and sockets slide into one pile in the shallow top drawer of a U.S. General Mini Toolbox. This 3×2 organizer grid drops into that drawer and gives each group its own bin, so you can grab one without dragging the rest along. Footprint: 215.5 × 140 × 26 mm, sized for the top drawer with clearance. Compartments: six bins, each about 69.7 × 67.6 mm. Walls and floor: 1.6 mm walls, 1.2 mm floor. Bin floors: 5 mm rounded bottom edges so small parts can be scooped out instead of trapped in square corners. Printing: one piece, no separate inserts or assembly. The grid works as a single tray: print it, drop it in, and lift the whole thing out when you need the drawer back. The rounded floors are part of the print, not loose scoops.
3×2 Drawer Organizer Grid for Mini Toolbox
A six-compartment drawer organizer sized to sit in the bottom drawer of a U.S. General mini toolbox. The 3×2 grid keeps small parts separated, with 1.6 mm outer and internal walls and a 1.2 mm floor. Each bin has a 5 mm concave scoop along the front and back wall, so fingers and small parts slide up the curve instead of catching on a square edge. The overall footprint is 215.5 × 140 × 51 mm. 3×2 grid, six bins 1.6 mm walls and 1.2 mm floor 5 mm finger-scoop fillets front and back in every bin Sized for the bottom drawer of a U.S. General mini toolbox
Seagate 1TB Hinged Drive Case
A hinged case for a 117 x 80 x 14.8 mm external drive, printed flat as one piece with a base, a cover and a flexible hinge between them. A snap latch on the opposite end holds the cover closed. Remix hooks Drive size: the inner cavity is the drive plus 1.5 mm in length and width and 1 mm in height. Change those numbers to fit another drive. Hinge strip: 0.6 mm thick and about 7 mm wide. Thicker is stiffer and longer-lived, thinner folds more easily. PETG is recommended. Latch: the cover tab is 30 mm wide and the base catch is 20 mm wide. Adjust either to change the closing force. Cable storage: the cable tray has been removed. A separate tray or a cable pocket could be added back on the cover's outer face. Both halves print without supports, with the cover opening facing up.
Gridfinity-Schraubenbox 2x1 ohne Label
Gridfinity-Behälter im Format 2x1 Units, 4 Units hoch (28 mm plus 4,4 mm Stapelrand), stapelbar, mit Halfgrid-Boden (4 × 2 Füße im 21-mm-Raster). Vorne läuft eine Rundung mit 18 mm Radius in den Boden aus, damit sich Schrauben und Kleinteile leicht herausschaufeln lassen. Die Vorderseite ist glatt, ohne Label-Mulde. Remix-Ansätze Rundung vorne: Radius 18 mm. Kleiner ergibt eine steilere Rampe, größer eine flachere Schräge mit weniger Restvolumen. Wandstärke und Boden: Wand 2,4 mm, Boden 5,5 mm. Beides lässt sich für leichtere oder robustere Boxen ändern. Label: Die Variante mit Label ergänzt eine 70 × 13 mm große Mulde, 0,8 mm tief, auf der Vorderseite. Alternativ lässt sich ein Schild aufkleben. Höhe: Die Höhe von 28 mm in Vielfachen von 7 mm anpassen, um andere Gridfinity-Höhen zu erhalten. Kombination: Passt auf Gridfinity-Baseplates mit 42-mm-Raster und stapelt mit gleichartigen Boxen. Vor dem Serienausdruck eine einzelne Zelle zur Passprobe drucken.
Открытая коробка с тремя круглыми отверстиями 65 мм
Открытая коробка размером 300 × 100 × 100 мм с толщиной стенок и пластин 4 мм. Обе длинные стороны полностью открыты, короткие торцы закрыты вертикальными стенками шириной 100 мм и высотой 96 мм над основанием. В верхней пластине — три круглых сквозных отверстия Ø65 мм; их центры расположены на 50, 150 и 250 мм по длине и по центру ширины. У каждого отверстия есть фаска 1 мм сверху и снизу, поэтому кромки ровные и гладкие. Коробка печатается одной деталью. Габариты: 300 × 100 × 100 мм Толщина стенок и пластин: 4 мм Длинные стороны открыты, торцы закрыты Три круглых сквозных отверстия Ø65 мм в верхней пластине Центры отверстий: 50, 150 и 250 мм по длине Фаски 1 мм по краям отверстий Печать одной деталью
Screw-Top Storage Jar With Lid
A 60 mm wide, 70 mm tall storage jar with a 50 mm threaded mouth and a matching screw-on lid. It suits spare screws, washers, small hardware or dry spices, and replaces a makeshift jam jar with something sized for the job. The thread is a coarse two-start design with an 8 mm pitch, so the lid goes on in about one turn and comes off just as quickly. The lid has a knurled grip band around its edge for a firm hold, and 0.4 mm of thread clearance to keep the two parts from fusing when printed. The thread fit has not been test-printed, so a small adjustment to clearance may be needed for your printer. Jar: 60 mm diameter, 70 mm tall including the neck Mouth: 50 mm threaded neck Lid: 60 mm diameter, 18 mm tall, knurled grip band Thread: coarse, two-start, 8 mm pitch Walls: 2.5 mm, with a 3 mm floor Printed as two separate pieces, jar and lid
Hot Wheels 1:64 Carrying Case
1:64 ölçekli Hot Wheels araçları için iki rafla ayrılmış üç bölmeli, altı parçalı taşıma kutusu. Dış genişlik menteşe dahil 90 mm, kapalı derinlik yaklaşık 49.4 mm, gövde ve kapak dış yüksekliği 111.4 mm'dir. İç derinlik yaklaşık 36 mm, her bölmenin iç yüksekliği 34.2 mm'dir. Gövde yuvarlatılmış köşelere sahiptir; raflar sağ tarafta menteşe boşluğu için yaklaşık 5 mm kısa biter. Ön açıklığa oturan kırmızı ızgara kapak 2 sütun × 3 sıra pencereye sahiptir; alt iki sıra raflarla hizalanır, üst sıra kilit bölgesi nedeniyle yaklaşık 12 mm yüksekliğindedir. Kapaktaki içe giren sol dikey çıkıntı üç parçaya bölünmüştür; rafların geçtiği yerlerde, her rafın üstünde ve altında 0.8 mm boşluk bırakan 3.6 mm yüksekliğinde girintiler vardır. Kilit, üst ön sol tarafta tek parça sert kanca-tırnak mandalıdır. Tüm parçalar PLA için tasarlanmıştır; mandalda ince veya esnek bükülen bölge yoktur. Mandal kolu 3 mm kalınlığında düz bir levhadır ve iki yan çıkıntısıyla gövdedeki iki direğin deliklerine oturur; ayrı pim kullanmaz. Kancanın ön alt kenarı ve kapaktaki tırnağın üstü eğimlidir: kapak kapanırken tırnak kancayı iter, kol hafifçe kalkar, tırnak geçince kanca geri düşer ve kapağı kilitler. Kanca tarafı pivottan daha uzun olduğu için kol kendiliğinden aşağı yatar. Açmak için kolun arkasındaki tırnağa başparmakla bastırın ya da öndeki çıkıntıyı yukarı kaldırın; tek elle açılır. Mandal, kolay takılıp çıkması için daraltılmıştır: kol 9 mm genişliğindedir ve iki direk arasında her yanda yaklaşık 1 mm boşluk kalır. Yan çıkıntılar 3.0 mm çapında ve 5.4 mm uzunluğundadır; gövdedeki direk delikleri 3.8 mm'dir, yani yarıçapta 0.4 mm boşluk vardır. Yalnızca mandalı yeniden basacaksanız eski 3.6 mm deliklerde de rahat girer. Kilit yerçekimine dayanır, bu yüzden kasa üstü yukarıda dururken veya kulpundan tutulurken devreye girer; ters ya da yan çevrildiğinde kanca düşmeyebilir ve kapak kilitsiz kalır. Kanca ile tırnak arasındaki yaklaşık 0.4 mm boşluk ve eğimlerin kapanışta takılmadan kayması deneme baskısında kontrol edilmelidir. Sağ taraftaki menteşede gövdede üç, kapakta iki boğum vardır; ayrı 3 mm pim 3.4 mm deliklerde durur ve delik tüm boğumlardan açık geçer. Katlanır U kulp üstte durur ve iki ayrı 2 mm pim etrafında döner; kollar pivot merkezinden öne doğru yaklaşık 23 mm uzanır ve 55.2 mm genişliğindeki ön çubuk kollara doğrudan bağlıdır. Pivot delikleri gövdedeki desteklerle aynı eksende hizalanır. Pimler ayrı parçadır; baskıdan sonra takılır ve çıkarılabilir. Kulp pimleri için 2 mm çelik çubuk daha sağlam sonuç verir. Mandal kolunun yan çıkıntılarını dik basmak katmanlar arasında kırılma riskini azaltır. Model plakada altı ayrı parça halinde durur ve baskıdan sonra monte edilir: Ana gövde: yuvarlatılmış, iki raflı ve üç bölmeli gövde; menteşe boğumları, kulp yuvaları ve mandal direkleri Kırmızı ızgara kapak: 2 × 3 pencereli, konumlandırma dudaklı, menteşe boğumlu ve mandal tırnaklı kapak; içe giren sol dikey çıkıntı üç parçalı ve raf girintileri 0.8 mm boşluklu Katlanır U kulp: kolları yaklaşık 23 mm, 55.2 mm ön çubuklu; iki ayrı pim üzerinde döner, kapalı konumda düşük profil verir Kulp pivot pimleri: iki ayrı 2 mm pim Kanca mandal: 9 mm genişliğinde tek parça sert kol, 3.0 mm yan çıkıntılı ve ön ucu kancalı Menteşe pimi: ayrı 3 mm pim, alt ucunda başlık Parçalar plakada birbirine değmeyecek şekilde ayrı yerleştirilmiştir; kapak gövdeden yaklaşık 8 mm ayrı durur. Mandal ve katlanır kulp hareketli mekanizmalardır; ilk baskıda boşluklarını ve hareketini kontrol edin. Pimler yuvarlak uçlarıyla plakaya küçük bir temas yüzeyiyle oturur; tutmazsa brim kullanın.
